A112
ECOTEC
| Quantity: | |
|---|---|
Ecotec design and manufacturing
Precise, convenient and safe, Customer and user first is the top priority in Ecotec design and manufacturing, J series is the dispenser with highest accuracy, quality, durability and reliability that always provides utmost satisfaction for all
Owner and User
Fuel dispenser J series is the essential dispenser for service stations, benefits to both service station owners and drivers, user-friendly and safe best partner that provide greatest fulfillment for all
Wide Range of product lineup
Product lineup meets various requirement of sites and customers, the best model with the best function,
suitable for single nozzle to 8 nozzle
suitable for both suction and submersible
suitable for Gilbarco, Tatsuno, Tokhem Bennett, LPG and CNG dispenser
suitable for regular flow rate and high flow rate
Option with TV, LED, Printer, Bank Card reader etc
Components with best cost performance
UL Listed motor Tatsuno Gear Pump Tatsuno Meter
Using the best motor from China which have both ATEX and UL listed, single phase, three phase available
Using the best Pump made in China, Tatsuno Gear Type inbuilt with Air separator , two stage of filter and bypass valve to adjust the pressure, water and ethanol resistant
Using the best Flow meter made in China, 4 Piston type provides safe refueling environment without deterioration in performance for a long period of time, also water and ethanol resistant
Flexible Function Design
Electronic Calibration available by preset keyboard and communication protocol
Long and short display value, Display sequence settable
Decimal position settable
Motor standby time adjustable to meet the different requirement
Fueling with integer, Ten bits, Hundred bit and Thousand bit
Re-display recall and settable
50 Filling record recall
Lock function, Lock by password, Lock by monthly control, Lock by remote control
Shift Record Printing
Ticket content settable, such as station name, address, products
Continue last interrupted fueling after power resume
Different Password control
Error Code to indicate the problem of dispenser
Integration with ITL, PTS, DOMS, Fusion
| Dispenser | Model | Product/ Pump | Flow Meter/ Nozzle/Hose | Display | Flow rate LPM |
| Suction type | H112S | 1 | 1 | 2 | 300-350L/M |
| Remote /Submersible type | H112R | 1 | 1 | 2 | 300-350L/M |
Specification:
| Pump | Type | Optional |
| Inlet Pressure | ≥54kPa. | |
| Flow rate (L/min.) | 300-350 | |
| Suction Distance (m) | 6(vertical meter) / 50(horizontal meter) | |
| Flow Meter | Type | Blade type flow meter |
| Accuracy | ±0.2% | |
| Motor | Voltage(V) | 380V,50Hz |
| Capacity(hp) | 10HP(7.5kw) | |
| Input Voltage | 380V,50Hz | |
| Nozzle | Auto Shut-off Nozzle 2inch option for loading arm | |
| Environmental Condition | -40ºC~~+55ºC | |
| Control Type | 2 inch Solenoid Vale Control Type | |
| Preset | Function Provided(Small LCD Indicator) | |
| Display(Counter) | Type | LCD and Bright Backlight |
| Digit of Volume | 0~~999,999(6 Digits),Decimal point can be changed | |
| Digit of Amount | 0~~999,999(6 Digits),Decimal point can be changed | |
| Digit of Unit price | 0~~9999(4 Digits),Decimal point can be changed | |
| Digit of Total Range | 0~~99,999,999,99 | |
| Totalizer | 1~~9,999,999 | |
| Hose | 4.5m | |
| Weight | 250kg | |
| Dimension(L×W×H) | 1060*600*1600(mm) | |
| Dimension(L×W×H)Of Qty of Container | 40ft: 44 20ft: 22 | |
Company Information
WENZHOU ECOTEC ENERGY EQUIPEMNT Co., Ltd as a professional supplier of Petroleum equipment, Energy device, can offer customer the better products with better price.
Ecotec Energy is founded in 2019, but the Ecotec team are all with experience for over 10 years. We can provide complete package service from Design, Manufacturing, Delivery and after-sale service, we have exported to over 60 countries now, and have agent in Africa, Middle East, Asia and South American countries.
Here Eectec Energy are on the position to offer the below products:
1. Fuel station: Fuel dispenser, Pump, Meter, fuel accessories, Adblue and container stations
2. LPG station: LPG dispenser, LPG pump, LPG meter, LPG Tank, LPG skid and other LPG station equipment
3. CNG station: CNG dispenser, CNG compressor, CNG cylinder and skid type CNG station
4. LNG Station: LNG dispenser, LNG pump, LNG pumping skid, LNG vaporizer etc
5. Valves for petroleum industrial: Ball valve, Gate Valve, Global valve, Check valve with different standard
6. Station Automation system: Station Retail system, Cell phone APP system, Tank Gauging system
7. Auto Parts: Tyre inflator, Wheel Balancer, Car Washing Machine etc
Customer and Dedication is what we standing for, we will always focus customer′s need, and struggle for it, Looking forward to cooperate with you
